CG125

No.156FMI‑2
Single‑cylinder, 4‑stroke, air‑cooled, manual clutch
Main Performance Features
SN Items Description
1 Modular Main & Counter Shaft Optimized gear ratio design for all gears on main and counter shafts to better meet application requirements.
2 Micro-arc Oxidation Piston Reduces friction and wear, lowers fuel consumption and improves durability. DLC surface treatment on piston rings cuts down wear and fuel consumption, enhancing reliability and service life.
3 High-Quality Piston Rings Dual DLC coated piston rings deliver excellent wear resistance and long service life, effectively slowing down oil burning.
4 Silent Cylinder Head Adopts bimetallic cylinder head and cast iron rocker arms for superior noise reduction performance.
Download
View all downloads
  • CG125,MY SHOP,CG125-MY SHOP
  • CG125,MY SHOP,CG125-MY SHOP
  • CG125,MY SHOP,CG125-MY SHOP
  • CG125,LITTLEDONKEY-ENGINE,CG125-MY SHOP

Description

Main Technical Specifications
SN Parameter Value
1 Engine Model 156FMI‑2
2 Engine Common Name CG125 Air‑Cooled
3 Engine Type Single‑cylinder,4‑stroke,air‑cooled,manual clutch
4 Displacement 124 ml
5 Max. Power 7.5 kW /9000 r/min
6 Max. Torque N/A
7 Compression Ratio 9.0:1
8 Bore × Stroke 56.5 mm ×49.5 mm
9 Ignition Method CDI
10 Lubrication Mode Pressure and Splash
11 Min. Fuel Consumption ≤354 g/kW·h
12 Starting Method Electric / Kick start
13 Clutch Manual Wet Multi‑Plate
14 Gearshift Constant‑mesh two‑stage transmission,5‑speed
15 Package Size 380 ×350 ×500
16 Package Weight
