| Main Performance Features | ||
| SN | Items | Description |
| 1 | Toothed timing chain drive: | 7‑piece toothed chain ensures stable valve‑train operation and low overall engine noise. |
| 2 | Cylinder‑head design: | Simple and generous profile with high heat dissipation efficiency. |
| 3 | Hot‑assembled crankcase: | Crankcase heated assembly reduces crankshaft axial‑play noise and improves overall engine performance. |
| 4 | High‑quality piston rings: | Dual DLC+PVD coated piston‑rings, outstanding wear‑resistance and long service‑life, effectively mitigate oil‑burning issues. |
| 5 | Dual‑starting modes: | Electric & kick‑start to satisfy diverse‑user requirements. |
|
Main Technical Specifications
|
||
| SN | Parameter | Value |
| 1 | Engine Model | 163FML |
| 2 | Engine Common Name | CB200 |
| 3 | Engine Type | Single‑cylinder, 4‑stroke, natural air‑cooled, inclined‑mount, overhead camshaft (OHC) |
| 4 | Displacement | 196.9 ml |
| 5 | Max. Power | 11 kW / 8000 r/min |
| 6 | Max. Torque | 15 N·m / 6500 r/min |
| 7 | Compression Ratio | 9.0:1 |
| 8 | Bore × Stroke | 63.5 mm × 62.2 mm |
| 9 | Ignition Method | CDI |
| 10 | Lubrication Mode | Pressure and Splash |
| 11 | Min. Fuel Consumption | ≤354 g/kW·h |
| 12 | Starting Method | Electric / Kick start |
| 13 | Clutch | Manual Wet Multi‑Plate |
| 14 | Gearshift | Constant‑mesh two‑stage transmission, 5‑speed |
| 15 | Package Size | 360 ×320×490 |
| 16 | Package Weight | |
