| Main Technical Specifications | |||
| SN | Parameter | Value | |
| 1 |
Engine Name |
ZS550SR | |
| 2 |
Engine Type |
2 cylinder in-line,4-stroke,8-valve，water-cooling, DOHC | |
| 3 |
Displacement (ml) |
550 | |
| 4 |
Bore × Stroke (mm) |
72×67.6 | |
| 5 |
Compression Ratio |
11:01:00 | |
| 6 |
Max. Power (kW/rpm) |
43.5/8500 | |
| 7 |
Max. Torque (Nm/rpm) |
55/6500 | |
| 8 |
Max. Speed (km/h) |
170 | |
| 9 |
Fuel System |
EFI | |
| 10 |
Ignition |
ECU | |
| 11 |
|
Electric | |
| 12 |
Brake |
Front/Rear: Disc, ABS | |
| 13 |
Tire |
Tubeless Tire;Front:120/70 ZR17；Rear:160/60 ZR17 | |
| 14 |
L×W×H (mm) |
2025×800×1165 | |
| 15 |
Wheelbase (mm) |
1460 | |
| 16 |
Seat Height （mm） |
800 | |
| 17 |
Min. Ground Clearance (mm) |
155 | |
| 18 |
Curb Weight (kg) |
204 | |
| 19 |
Fuel Tank Capacity (L) |
20 | |
| 20 |
Container Loading Quantity (40'HQ) |
32 | |
